Full Taper Polished Forks (FTP)

Often referred to as Lumber Forks or Plywood Forks, these fork tines are different than standard taper forks in the sense that the taper starts near the heel and continues all the way to the the tip of the fork.

Tips on fully tapered forks are typically squared off, with a chisel tip making them on the tips thinner than standard forks. The purpose of this style fork is to effectively and efficiently lift bundles of wood building material without damaging the load with a forged finish or narrower contact surface.

FTP Style Forks are also used frequently when "scooping" un-palletized loads directly off of the ground or floor. The Full Bottom Taper allows the chisel tip to sit directly on the ground to be effective in this application.

See a larger selection of  FTP Forks in the Shop

Full Taper Forks
Model No. Mounting Class T x W x L Capacity @24" LC
Buy Now
2-150648FT II 1.5 x 6 x 48 5,500 Click here to Buy Now
3-150742FT
III 1.5 x 7 x 42
7,500
Click here to Buy Now
3-150748FT
III 1.5 x 7 x 48
7,500
Click here to Buy Now
3-150848FT
III 1.5 x 8 x 48
9,000
Click here to Buy Now
4-1501048FT
IV
1.5 x 10 x 48
13,000 Click here to Buy  Now
4-1501248FT
IV
1.5 x12 x 48
16,000
Click here to Buy Now



Lumber or Plywood Forks:

Lumber Forks or Full-Tapered Forks or Full-Taper and Polished Forks are made with a typical maximum thickness of 1.5 inches and in various widths, depending on the load weight.  They are all made as full bottom taper forks, meaning the taper runs from the tip , back to approx. 2 inches from the bend.  The top of the blade is polished, unpainted, for ease of entry and exit.  Tips are thin with a top chamfer for chiseling between plywood sheets and the tips are squared off, not rounded, to assist the chiseling effort.
