FORK CLAMPS
PALLET FORK CLAMPS FROM FORK-CO ARE AVAILABLE IN SIDESHIFTING, NON-SIDESHIFTING AND REVOLVING MODELS. A wide selection of forks and opening range options are available. Forks are integral with the arm slide bars.
E-profile aluminum frame segments are protected by full length composite bearings. The cartridge-type valve is easily serviced and truck connections are clean and accessible.
Class II and Class III mounting types are available in zero degree so the forks can easily enter stacked pallets and bins.
Slip-on arms can be used to handle different loads by clamping them, such as drum arms, multi-purpose rubber surfaced arms, bale arms or rotating drum pads for dumping forward
MULTI PURPOSE & RIGID ARM CARTON CLAMPS are used for handling palletless corrugated fiber board cartons and boxes, wooden bins and crates, totes and lugs and in many bale applications where totes, bins, Gaylords etc. are common.
Arms surface is aluminum bonded to vulcanized grooved rubber to ensure secure grip and long life. The bolted rubber surface is replaceable.
Available in standard and custom opening ranges as well as custom arm lengths and heights.
Arms are very thin profile for easy load entry. Tips of the arms are protected by steel guards to preserve the surface integrity.
-
REVOLVING 360 DEGREE ROTATION
-
CAPACITIES FROM 3,000 LB TO 7,000 LB
-
ADJUSTABLE ARM TRAVEL SPEEDS
-
E-PROFILE ALUMINUM FRAME
-
T-BAR ALLOY STEEL ARM CARRIERS
-
SELF-ALIGNING CYLINDERS
-
LUBE-FREE CONTOURED ARM BEARINGS
-
CYLINDER PROTECTION BUMPER
-
STEEL ABRASION PROTECTION
-
PROVEN DESIGN
-
LOW PROFILE FRAME
